VACON® NXP IP00 Drive Modules
Operating Guide
8.7.8.9 Pre-charge Mode (P6.7.6)
For an FI9 or a larger inverter unit, select Ext.ChSwitch to control an external charge switch.
8.7.9 System Info
8.7.9.1 Finding the System Info Menu
The System info submenu (S6.8) contains information on the hardware, software, and operation of the AC drive.
Procedure
1.
To find the System info submenu, scroll down in the System menu until the location indication S6.8 shows on the first line of
the display.
2.
To go to the System info submenu from the System menu, push the Menu button Right.
8.7.9.2 Total Counters (S6.8.1)
The Total counters page (S6.8.1) has information on the AC drive operation times. The counters show the total number of MWh,
operation days, and operation hours. The Total counters cannot be reset.
The Power On time counter (days and hours) always counts, when the AC power is on. The counter does not count when control
unit runs on +24 V only.
Table 24: Total Counters
Page
Counter
C6.8.1.1.
MWh counter
C6.8.1.2.
Power On day counter
C6.8.1.3
Power On hour counter
8.7.9.3 Trip Counters (S6.8.2)
The Trip counters page (S6.8.2) has information on resettable counters, that is, counters, for which the value can be set back to 0. The
trip counters count only when the motor is in RUN state.
Table 25: Trip Counters
Page
Counter
T6.8.2.1
MWh counter
T6.8.2.3
Operation day counter
T6.8.2.4
Operation hour counter
8.7.9.4 Resetting the Trip Counters
Use these instructions to reset the trip counters.
Procedure
1.
In the System info submenu, find the Trip counters page (6.8.2) with the Browser buttons.
2.
To go to the Clear MWh counter page (6.8.2.2, Clr MWh cntr) or to the Clear Operation time counter page (6.8.2.5, Clr Optime
cntr), use the Menu button Right.
3.
To go to the edit mode, push the Menu button Right.
4.
To select Reset, push Browser buttons Up and Down.
5.
To accept the selection, push the [enter] button.
6.
The display shows again Not reset.
Danfoss A/S © 2023.09
Example
Value on display is 1.013. The drive has operated for 1 year and 13 days.
Value on display is 7:05:16. The drive has operated for 7 hours 5 minutes and 16 s.
Example
–
Value on display is 1.013. The drive has operated for 1 year and 13 days.
Value on display is 7:05:16. The drive has operated for 7 hours 5 minutes and 16 s.
Using the Control Panel
AQ351737303996en-000201 / DPD00888 | 105
