VACON® NXP IP00 Drive Modules
Operating Guide
Procedure
1.
Fasten the mounting box with the control unit to a sidewall or to the frame of the enclosure.
The standard length of the connecting cable and the fiber optic cables is 2.3 m, so the control unit must be placed within
this distance from the power unit. Pay attention to the minimum bending radius of the fibre optic cables
Connections.
2.
To ensure a proper grounding of the control unit assembly, we recommend that an extra grounding cable is drawn from
the mounting box and connected to the cabinet frame. Use a braided copper cable designed for high frequency signals.
In
Illustration
18, the control unit is mounted on a hinged assembly box (not included in standard delivery) in front of the power
unit, FR8–FR12.
Illustration 18: Mounted Control Unit, FR8–FR12
5.5.2 Installation Sequence for FR13–FR14
Use these instructions to install the VACON
Check the following:
•
Environmental requirements, see
•
Cooling requirements, see
•
Cabinet requirements, see
•
The dimensions of the AC drive, see
Procedure
1.
Install the AC chokes, see
2.
Install the power unit, see
3.
If the drive was ordered with the control unit separated from the power unit, install the control unit, see
the Control Unit,
FR13–FR14.
The VACON
NXP FR10–FR12 drive can be delivered with the control unit either integrally mounted on the power unit or
®
separated from the power unit and fixed to the mounting box. The mounting box can be installed to a sidewall or the
frame of the enclosure.
4.
Make sure that there is sufficiently free space around the AC drive for cooling, see
space is also necessary for maintenance.
5.
Continue to the grounding and cabling, see
5.5.2.1 Mounting the AC Chokes, FR13–FR14
This topic gives instructions on how and where to mount the AC choke in the cabinet for VACON® NXP IP00 Drive Module, FR13–
FR14.
Check the needed amount and type of chokes in
40 | Danfoss A/S © 2023.09
NXP IP00 Drive Modules.
®
5.1 Environmental Requirements
5.2 Cooling Requirements
5.4 Cabinet Requirements for FR13–FR14
12.3.3 List of Dimension Information
5.5.2.1 Mounting the AC Chokes,
5.5.2.2 Mounting the Power Unit,
6.7 Installing the
12.5 AC Chokes
FR13–FR14.
FR13–FR14.
5.2 Cooling
Cables.
and
5.4 Cabinet Requirements for
Mounting the Unit
7.4 Fiber Cable
5.5.2.3 Mounting
Requirements. Some free
FR13–FR14.
AQ351737303996en-000201 / DPD00888
