VACON® NXP IP00 Drive Modules
Operating Guide
Example 3
A
5
A1
1
1
U
dUdt
2
2
PE
Illustration 13: Example Installation 3
1
NFE units
2
AC chokes
3
FI13 (inverter unit)
Table 13: Cabinet Data for Installation Example 3
This installation applies to drive types:
Minimum required cabinet width:
Minimum required cabinet height:
Required weight carrying capacity:
Protection rating:
Construction:
Ventilation openings:
Danfoss A/S © 2023.09
B
C
5
5
A1
3
1
1
V
W
4
2
2
NXP1300 5 (12-pulse)
NXP1450 5 (12-pulse)
600 mm (Cab. A) + 800 mm (Cab. B) + 600 mm (Cab. C)
(23.62 in (Cab. A) + 31.50 in (Cab. B) + 23.62 in (Cab. C))
2200 mm
(86.61 in)
450 kg (992.08 lb) (Cab. A and C); 540 kg (1190.5 lb) (Cab. B)
This manual applies to IP21.
According to EN60439-1
See
4
dU/dt filter
5
DC busbars
5.2.1 Ventilation of the
Cabinet.
Mounting the Unit
AQ351737303996en-000201 / DPD00888 | 35
