VACON® NXP IP00 Drive Modules
Operating Guide
8.4.3 Changing the Control Mode
3 control modes are available to control the AC drive. For each control place, a different symbol shows on the display:
The control mode
I/O terminals
Keypad (control panel)
Fieldbus
Procedure
1.
In the Keypad control menu (M3), find the control mode (Control Place) with Menu buttons Up and Down.
Control Place
I/O Terminal
2.
To go to the edit mode, push the Menu button Right.
The parameter value starts to blink.
3.
To scroll through the options, push the Browser buttons Up and Down.
4.
To select the control mode, push the [enter] button.
8.4.4 Keypad Reference
The keypad reference submenu (P3.2) shows the frequency reference. In this submenu, also the frequency reference can be edited.
8.4.4.1 Editing the Frequency Reference
Use these instructions to change the frequency reference.
Procedure
1.
In the Keypad control menu (M3), find the Keypad reference with Menu buttons Up and Down.
2.
To go to the edit mode, push the Menu button Right. The frequency reference value starts to blink.
3.
Set the new value with the Browser buttons.
The value changes only on the control panel.
4.
To make the motor speed to agree with the value on the control panel, select the keypad as the control mode, see
Changing the Control
8.4.5 Changing the Rotation Direction
The keypad direction submenu shows the rotation direction of the motor. In this submenu, also the rotation direction can be
changed.
For more information on how to control the motor with the control panel, see
Procedure
1.
In the Keypad control menu (M3), find the Keypad direction with the Menu buttons Up and Down.
2.
To go to the edit mode, push the Menu button Right.
90 | Danfoss A/S © 2023.09
STOP
READY
I/O term
Mode.
Using the Control Panel
The symbol
I/O term
Keypad
Bus/Comm
3.6.1 Keypad
and
9.2 Commissioning the AC
AQ351737303996en-000201 / DPD00888
8.4.3
Drive.
