12.4.6 Busbar and Terminal Dimensions for 525–690 V
choke connections.
L1
1
2
3
Illustration 39: Power Input Terminals and Busbars to AC Choke
1
Input terminals
2
Installation plate
8.
Connect a grounding cable from the grounding connector at the lower right hand side of the power unit frame to the PE
busbar of the enclosure. Use a copper grounding cable with a cross-sectional area of at least 2*35 mm
which obeys the local regulations for grounding cables.
Illustration 40: Grounding the power unit, FR11
1
Grounding cable
2
PE busbar
62 | Danfoss A/S © 2023.09
L2 L3
1
AC. Also see
6.4 AC Choke Connections
3
AC choke input terminals
2
3
Grounding terminal
Electrical Installation
for information about AC
1
2
3
2
per power unit,
3
1
AQ351737303996en-000201 / DPD00888
