VACON® NXP IP00 Drive Modules
Operating Guide
Code Function
I6.8.5.3 Info: Brake chopper
I6.8.5.4 Info: Brake resistor
S6.8.6 Expander boards
S6.8.7 Debug menu

8.7.3 Changing the Language

Use these instructions to change the language of the control panel. The possible languages are different in all language packages.
Procedure
1. In the System menu (M6), find the Language selection page (S6.1) with the Browser buttons.
2. To go to the edit mode, push the Menu button Right.

The name of the language starts to blink.
3. To select the language for the control panel texts, use the Menu buttons Up and Down.
4. To accept the selection, push the [enter] button.

The name of the languages stops to blink and all text information on the control panel shows in the selected lan-
guage.

8.7.4 Changing the Application

The application can be changed in the Application selection page (S6.2). When the application is changed, all parameters are reset.
For more information on the Application Package, see VACON
Procedure
1.
In the System menu (M6), find the Application selection page (S6.2, Application) with the Browser buttons.
2. Push the Menu button Right.
3.
To go to the edit mode, push the Menu button Right.

The name of the application starts to blink.
4. Scroll through the applications with the Browser buttons and select a different application.
5. To accept the selection, push the [enter] button.

The AC drive starts again and goes through the set-up.
6.
When the display shows the question Copy parameters?, there are 2 options:
This question shows only if the parameter P6.3.4 Parameter back-up is set to Yes.
- To upload the parameters of the new application to the control panel, select Yes with the Browser buttons.
-
To keep the parameters of the application that was last used in the control panel, select No with the Browser buttons.

8.7.5 Copy Parameters (S6.3)

Use this function to copy parameters from one AC drive to a different AC drive or to save parameter sets in the internal memory of
the AC drive.
Stop the AC drive before copying or downloading parameters.
Danfoss A/S © 2023.09
Min Max Unit
– – –
– – –
– – –
– – –
NX All in One Application Manual.
®
Using the Control Panel
Default Cust Description
– –
– –
– –
– For Application program-
ming only. Speak to the
factory to get instructions.
AQ351737303996en-000201 / DPD00888 | 97
