VACON® NXP IP00 Drive Modules
Operating Guide
Ø5
154.2
126
Illustration 89: Control Unit Dimensions

12.4 Cable and Fuse Sizes

For cable, and fuse size information, see the following topics:
• 380–500 V AC:
- 12.4.1 Internal Cable Sizes for 380–500 V AC
- 12.4.2 Busbar and Terminal Dimensions for 380–500 V AC
- 12.4.3 Fuse Sizes for 380–500 V AC, 6-pulse
- 12.4.4 Fuse Sizes for 380–500 V AC, 12-pulse
• 525–690 V AC:
- 12.4.5 Internal Cable Sizes for 525–690 V AC
- 12.4.6 Busbar and Terminal Dimensions for 525–690 V AC
- 12.4.7 Fuse Sizes for 525–690 V AC, 6-pulse
- 12.4.8 Fuse Sizes for 525–690 V AC, 12-pulse
12.4.1 Internal Cable Sizes for 380–500 V AC
Table 34: Cable Sizes for 380–500 V AC, FR8–FR12
Enclosure size Drive type
FR8 NXP 0140 5
NXP 0168 5
NXP 0205 5
FR9 NXP 0261 5
NXP 0300 5
132 | Danfoss A/S © 2023.09
82.8
Ø5
Ø10
Temperature rating
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
Internal cable/phase [mm
(1)
70
95
70
95
95
120
2*70
2*95
2*70
2*95
AQ351737303996en-000201 / DPD00888
Specifications
2
]
