VACON® NXP IP00 Drive Modules
Operating Guide
Table 30: Mounting Dimensions, in
A
B
C
1.97
3.94
44.09
If the AC choke is installed in another location, the distance must not, however, be smaller than what is given in parentheses.
1
If the control unit is installed in any other location, the minimum distance from the door equals the number in parentheses.
2
12.3.2 Mounting Dimensions, FR13–FR14
Illustration 76: Mounting Dimensions, FR13-FR14
A
Minimum distance from the top of the cabinet. This
space is needed for the fuses and busbars.
B
Unit height
Table 31: Mounting Dimensions, mm
A
175
If the AC choke is installed in another location, the distance must not, however, be smaller than what is given in parentheses.
1
Table 32: Mounting Dimensions, in
A
6.89
1
If the AC choke is installed in another location, the distance must not, however, be smaller than what is given in parentheses.
12.3.3 List of Dimension Information
This topic gives a list of dimension information for different types of VACON
Danfoss A/S © 2023.09
D
21.65 (11.42)
(1)
A
B
C
B
1050
B
41.34
E
4.57 (1.73)
(2)
C
Minimum distance from the bottom of the enclo-
sure if the AC choke is installed at the bottom of the
enclosure.
C
600 (300)
(1)
C
23.62 (11.81)
(1)
NXP IP00 Drive Modules.
®
Specifications
F
G
36.14
33.46 (23.23)
(1)
AQ351737303996en-000201 / DPD00888 | 121
