VACON® NXP IP00 Drive Modules
Operating Guide
Technical item or function
Altitude
Vibration: EN50178/EN60068-2-6
Shock: EN50178, EN60068-2-27
Protection rating
Pollution degree
EMC (at default set- Immunity
tings)
Emissions
Noise level Average noise level (cooling fan) in
dB(A)
Functional safety
Hardware based 'Safe Torque Off'
safety function to prevent the drive
from generating torque on the motor
shaft.
STO safety function has been de-
signed for use in accordance with the
following standards
SS1 safety function is realized in com-
pliance with type C of the drives safe-
ty standard EN61800-5-2 (Type C:
"The PDS(SR) initiates the motor de-
celeration and initiates the STO func-
tion after an application specific time
delay"). SS1 safety function has been
designed for use in accordance with
the following standards:
ATEX thermistor input
Approvals -
Efficiency -
Control connections Analog input voltage
(factory default I/O)
148 | Danfoss A/S © 2023.09
Technical data
100% load capacity (no derating) up to 1000 m 1-% derating for
each 100 m above 1000; maximum 3000 m (690 V max 2000 m).
Displacement amplitude 0.25 mm (peak) at 5–31 Hz Max acceler-
ation 1 G at 31–150 Hz. Use anti-vibration mountings under the
drive if extra vibration resistance is required.
UPS Drop Test (for applicable UPS weights) Storage and shipping:
max 15 G, 11 ms (in package)
IP21/NEMA1 standard in entire kW/HP range IP54/NEMA12 op-
tion in entire kW/HP range.
PD3
Fulfills all EMC immunity requirements
EMC level L: EN 61800-3 (2004), Category C3 EMC level T: Low
earth-current solution for IT-networks, EN 61800-3 (2004), Cate-
gory C4 (can be modified from level L units.
The sound pressure depends on the cooling fan speed, which is
controlled in accordance with the drive temperature.
FR8: 58
FR9–FR13: 76
FR14: 78
• EN 61800-5-2 Safe Torque Off (STO) SIL3
• EN ISO 13849-1 PL "e" Category 3
• EN 62061 SILCL3
• IEC 61508 SIL3
• The function also corresponds to an uncontrolled stop in ac-
cordance with stop category 0, EN 60204-1.
• EN 954-1, Category 3
• EN 61800-5-2 Safe Stop 1 (SS1) SIL3
• EN ISO 13849-1 PL "e" Category 3
• EN 62061 SILCL3
• IEC 61508 SIL3
• The function also corresponds to a controlled stop in accord-
ance with stop category 1, EN60204-1.
2014/34/EU, CE 0537 Ex 11 (2) GD
EN 50178 (1997), EN 60204-1 (1996), EN 60950 (2000, 3rd edition)
(as relevant), CE, UL, CUL, EN 61800-5; (see unit nameplate for
more detailed approvals). IEC 60664-1 and UL840 in overvoltage
category III.
See http://ecosmart.danfoss.com/
0...+10 V, R = 200 kW, (–10 V...+10 V joystick control) Resolution
i
0.1%, accuracy ±1%
