Table 44: Fuse Sizes (Bussmann) for 380–500 V AC, FR13–FR14, 12-pulse
Enclosure Drive Fuses with flush end contact
size type (metric)
Fuse part nr. (aR)
(AC/DC)
FR13 1150 170M6466
1300 170M6466
1450 170M6466
FR14 1770 170M6466
2150 170M6466
Table 45: Fuse Sizes (Ferraz Shawmut) for 380–500 V AC, FR10–FR12, 12-pulse
Enclo- Drive Fuse
sure size type size
FR10 385 2
460 2
520 2
12.4.5 Internal Cable Sizes for 525–690 V AC
Table 46: Cable Sizes for 525–690 V AC, FR8–FR12
Enclosure size Drive type
FR8 NXP 0062
NXP 0080
NXP 0100
FR9 NXP 0125
NXP 0144
NXP 0170
NXP 0208
FR10 NXP 0261–0416
136 | Danfoss A/S © 2023.09
Fuses with flush end contact
(US)
Fuse size Fuse part nr.
(aR)
3BKN/50 170M6566
3BKN/50 170M6566
3BKN/50 170M6566
3BKN/50 170M6566
3BKN/50 170M6566
DIN 43620 DIN 43653 (80
mm)
2 PV 0450 32 D08A 0450
2 PV 0450 32 D08A 0450
2 PV 0450 32 D08A 0450
Temperature rating
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
90 °C (194 °F)
70 °C (158 °F)
Fuse In
[A]
Fuse size
3GKN/50 1250
3GKN/50 1250
3GKN/50 1250
3GKN/50 1250
3GKN/50 1250
DIN 43653 Threaded end
(110 mm) contacts (metric)
32 D11A 0450 32 TTF 0450
32 D11A 0450 32 TTF 0450
32 D11A 0450 32 TTF 0450
Internal cable/phase [mm
(1)
25
35
25
35
35
50
50
70
70
95
70
95
95
120
2*70
2*95
