VACON® NXP IP00 Drive Modules
Operating Guide
Procedure
1.
Find the parameter with the Browser and Menu buttons.
Min Frequency
2.
To go to the Edit mode, push the Menu button Right. The parameter value starts to blink.
Min Frequency
3.
Push the Menu button Right. The value can now be edited digit by digit.
4.
To accept the change, push the [enter] button.
To ignore the change, push Menu button Left many times, until the view goes back to the parameter list.
If the [enter] button is pushed, the value stops to blink and the new value shows in the value field.
Min Frequency
5.
For locking the parameter values, use the Parameter Lock function in menu M6, see
88 | Danfoss A/S © 2023.09
READY
Keypad
13.95 Hz
READY
Keypad
13.95 Hz
READY
Keypad
14.45 Hz
Using the Control Panel
8.7.6.6 Locking a
Parameter.
AQ351737303996en-000201 / DPD00888
