3.6 Control Panel

3.6.1 Keypad

The VACON keypad has 9 buttons with which to control the AC drive (and motor), set parameters, and monitor values.
®
A B
L
ready run fault
K
reset
J
select
I
Illustration 2: Keypad Buttons for VACON
Danfoss A/S © 2023.09
Description
These AC drives comply with the standard IEC/EN 61800-3 + A1 if they are used in IT
systems. In IT systems, the networks are isolated from ground, or connected to ground
through high impedance to decrease the leakage current.
If the AC drives are used with other supplies, they do not comply with the EMC re-
quirements.
The AC drives of this category do not give EMC emission protection. These drives are
installed in enclosures.
An external EMC filter is usually necessary to comply with the EMC emission require-
ments.
RADIO INTERFERENCE
In a residential environment, this product can cause radio interference.
-
Take supplementary mitigation measures.
