12.3.4 Dimensions for Power Units

12.3.4.1 Dimensions for Power Unit, FR8
Ø
W2
Illustration 77: Dimensions of the VACON® NXP IP00 AC Drive, FR8
Table 33: Dimensions in mm (in inch) of the VACON
Drive type
• 0140 2–0205 2
• 0140 5–0205 5
• 0062 6–0100 6
122 | Danfoss A/S © 2023.09
NXP IP00 AC Drive, FR8
®
W1 W2
291 255
(11.47) (10.04)
H1
W1
H1 H2
758 732
(29.88) (28.81)
AQ351737303996en-000201 / DPD00888
Specifications
D1 Ø
344 9
(13.54) (0.35)
