VACON® NXP IP00 Drive Modules
Operating Guide
Code
Description
5
The mains voltage:
•
5 = 380–500 V
•
6 = 525–690 V
A
The control panel:
•
A = Standard (text display)
•
B = No local control panel
•
F = Dummy keypad
•
G = Graphical display
0
The protection rating:
•
0 = IP00 (drive module only)
N
The EMC emission level:
•
N = No EMC emission protection. Requires cabinet assembly to comply with level L
•
T = Complies with the standard IEC/EN 61800-3 + A1 when used in IT networks (C4).
The brake chopper:
0
•
0 = No brake chopper
•
1 = Internal brake chopper
SSG
The hardware changes:
•
The supply, the first letter (Xxx):
-
-
-
-
-
-
•
The mounting, the second letter: (xXx):
-
-
•
The boards, the third letter (xxX):
-
-
-
-
-
-
-
-
A1A20000E3
The option boards. 2 characters for each slot. 00 = the slot is not used
18 | Danfoss A/S © 2023.09
S = Standard 6-pulse with chokes
B = 6-pulse with choke and DC connection
N = 6-pulse, no chokes for spare units
T = 12-pulse
U = 12-pulse, no chokes for spare units
H = 6-pulse, no AC chokes, and with DC connection for spare units
S = Air-cooled drive
O = DC fan external supply
F = Direct connection/non varnished
G = Direct connection/varnished
A = Fiber,integrated control
B = Fiber,integrated control, Varnished
N = IP54 control unit for standard/fiber connection
O = IP54 control unit for varnished/fiber connection
X = IP00 for cabinet use, standard PCB
Y = IP00 for cabinet use, standard PCB, varnished
