VACON® NXP IP00 Drive Modules
Operating Guide
8.7.9.5 Software (S6.8.3)
The Software information page includes information on the AC drive software.
Page
6.8.3.1
6.8.3.2
6.8.3.3
6.8.3.4
8.7.9.6 Applications (S6.8.4)
The Applications submenu (S6.8.4) contains information on all applications on the AC drive.
Page
6.8.4.#
6.8.4.#.1
6.8.4.#.2
6.8.4.#.3
8.7.9.7 Examining the Application Page
Use these instructions to examine the Applications pages.
Procedure
1.
In the System info submenu, find the Applications page with the Browser buttons.
2.
To go to the Applications page, push the Menu button Right.
3.
To select the application, use the Browser buttons. There are as many pages as there are applications on the AC drive.
4.
To go to the Information pages, use the Menu button Right.
5.
To see the different pages, use the Browser buttons.
8.7.9.8 Hardware (S6.8.5)
The Hardware information page includes information on the AC drive hardware.
Page
6.8.5.1
6.8.5.2
6.8.5.3
6.8.5.4
6.8.5.5
106 | Danfoss A/S © 2023.09
Content
Software package
System software version
Firmware interface
System load
Content
Name of application
Application ID
Version
Firmware interface
Content
Power unit type code
Nominal voltage of the unit
Brake chopper
Brake resistor
Serial number
Using the Control Panel
AQ351737303996en-000201 / DPD00888
