VACON® NXP IP00 Drive Modules
Operating Guide
Example 1
A
5
A1
1
1
U
dUdt
2
2
PE
Illustration 11: Example Installation 1
1
NFE units
2
AC chokes
3
FI13 (inverter unit)
Table 11: Cabinet Data for Installation Example 1
This installation applies to drive types:
Minimum required cabinet width:
Minimum required cabinet height:
Required weight carrying capacity:
Protection rating:
Construction:
Ventilation openings:
Danfoss A/S © 2023.09
B
5
3
V
W
4
NXP1150 5
NXP0920 6
NXP1030 6
NXP1180 6
600 mm (Cabinet A) + 800 mm (Cabinet B)
(23.62 in (Cabinet A) + 31.50 in (Cabinet B))
2200 mm
(86.61 in)
NXP1150 5: 480 kg (1058.2 lb) (Cab. A); 540 kg (1190.5 lb) (Cab. B)
NXP0920 6: 450 kg (992.1 lb) (Cab. A); 540 kg (1190.5 lb) (Cab. B)
NXP1030 6: 450 kg (992.1 lb) (Cab. A); 540 kg (1190.5 lb) (Cab. B)
NXP1180 6: 480 kg (1058.2 lb) (Cab. A); 540 kg (1190.5 lb) (Cab. B)
This manual applies to IP21.
According to EN60439-1
See
5.2.1 Ventilation of the
4
dU/dt filter
5
DC busbars
Cabinet.
AQ351737303996en-000201 / DPD00888 | 33
