VACON® NXP IP00 Drive Modules
Operating Guide
Technical item or function
Input frequency
Connection to mains
Supply grounding system
Short circuit ratings
Motor connection
Output voltage
Continuous output current
Starting current
Output frequency
Control qualities
Control performance
Switching frequency
Frequency reference
•
•
Field weakening point
Acceleration time
Deceleration time
Braking
Ambient conditions
Ambient operating temperature
Storage temperature
Relative humidity
Air quality:
•
•
Cabinet surface treatment
Danfoss A/S © 2023.09
Analog input
Panel reference
chemical vapors
mechanical particles
Technical data
380–500 V; 525–690 V; –10%...+10% (low harmonic drives)
45–66 Hz
Once per minute or less (normal case)
TN-S, TN-C, TN-CS, TT or IT
Defined by ratings of installed fuses or circuit breakers. Maximum
permitted values 50 kA at 380–500 V AC, 40 kA at 525–690 V AC.
Refer to cabinet specific documentation for more details
0—U
in
Ambient temperature maximum +40 °C (+104 °F), up to +50 °C
(+122 °F) with current derating 1.5% per 1°. See
ings for Mains Voltage 380–500 V
Mains Voltage 500–690
V.
Is for 2 s every 20 s
0–320 Hz; (higher with special software)
•
Open Loop Vector Control (5–150% of basic speed): Speed
control 0.5%, dynamic 0.3%/s, torque lin. <2%, torque rise
time ~5 ms
•
Closed Loop Vector Control (entire speed range): Speed con-
trol 0.01%, dynamic 0.2%/s, torque lin. <2%, torque rise time
~2 ms
NX_5: 1–6 kHz; Factory default 3.6 kHz
NX_6: 1–6 kHz; Factory default 1.5 kHz
•
Resolution 0.1% (10-bit), accuracy ±1%
•
Resolution 0.01 Hz
8–320 Hz
0.1–3000 s
0.1–3000 s
DC brake: 30% x T
(without brake option); flux braking
N
–10 °C (no frost)...+40 ºC (+14 °F (no frost)...+104 °F)
–40 °C...+70 °C (-140 °F...+158 °F)
0–95% RH, non-condensing, non-corrosive, no dripping water
Designed according to
•
IEC 60721-3-3 Edition 2.2, AC drive in operation, class 3C3
•
IEC 60721-3-3 Edition 2.2, AC drive in operation, class 3S2
Nano ceramic pretreatment. Anodic dip-coat priming and tex-
tured powder-coating.
AQ351737303996en-000201 / DPD00888 | 147
Specifications
