■ SETTING RANGE OF ANALOG OUTPUTS 0% AND 100%
The analog outputs 0% and 100% can be set within the range of -20000 to 100000. The default values per input type are
as shown in the following tables.
• INPUT CODE: 1 [MODEL: 47DAC-1XX-XX]
INPUT TYPE
(MAIN DISPLAY)
0 – 0.2 V
(0.2V)
0 – 2 V
(2V)
0 – 20 V
(20V)
0 – 200 V
(200V)
• INPUT CODE: 2 [MODEL: 47DAC-2XX-XX]
INPUT TYPE
(MAIN DISPLAY)
0 – 0.2 mA
(0.2MA)
0 – 2 mA
(2MA)
0 – 20 mA
(20MA)
0 – 200 mA
(200MA)
IMPORTANT
• The operational range of the DC output is -10 to +110% of the output span after analog output 0% and 100% adjust-
ments.
• The output is saturated at approximately -10% or +110%.
• The analog outputs 0% and 100% are returned to the previously set values per input type (or default values when the
input type is selected for the first time) when the input type has been changed.
• The analog outputs 0% and 100% can be set to any value, however it is recommended to use them within the set dis-
play scaling range.
DEFAULT VALUE
Analog output 0%:
Analog output 100%:
Analog output 0%:
Analog output 100%:
Analog output 0%:
Analog output 100%:
Analog output 0%:
Analog output 100%:
DEFAULT VALUE
Analog output 0%:
Analog output 100%:
Analog output 0%:
Analog output 100%:
Analog output 0%:
Analog output 100%:
Analog output 0%:
Analog output 100%:
