36. APPENDICES

36.1 SPECIFICATIONS

■ GENERAL SPECIFICATIONS
Construction
Degree of protection
Connection Input, DC output, relay
output, network inter-
face, power
Photo MOSFET relay,
event trigger input
BCD output
Screw terminal
Housing material
Isolation
Infrared communication
Setting (front button) Scaling setting mode
Alarm setting mode
Advanced setting mode
Lockout setting mode
Modbus setting mode
Loop test output
Read rate
Averaging
Lockout setting
Panel flush mounting
IP66; Applicable to the front of the panel meter mounted according to the specified
panel cutout.
M3 separable screw terminal (torque 0.6 N·m)
Euro Type Connector Terminal
Applicable wire size: max. 1.3 dia., 0.5 – 1.25 mm
50-pin connector (Honda Tsushin Kogyo HDR-EC50LFDT1-SLE+)
Nickel-plated steel (standard) or stainless steel
Flame-resistant resin (gray)
Input to DC output to HH output or H output to L output or LL output to network or
BCD output or event trigger input to power
Transmission distance max. 1 meter (for use with the COP-IRU)
Input type, input scaling value Zero and Span, display scaling value Zero and
Span, decimal point position, bargraph type, bargraph lower limit, bargraph upper
limit, analog output type, analog output function mode, analog output 0%, analog
output 100%, analog output 0% adjustment, analog output 100% adjustment
Bank No., alarm output pattern, HH, H, L and LL alarm setpoint, HH, H, L and LL
trip action, HH, H, L and LL deadband (hysteresis), HH, H, L, LL and P ON delay
time, HH, H, L, LL and P OFF delay time, HH, H, L, LL and P one-shot output, HH,
H, L, LL and P coil at alarm, main display blinking at alarm, bank copy
Event trigger mode, ON timing delay, OFF timing delay, startup timer, averaging
type, averaging time, low-end cutout, low-end cutout value, display color, automatic
return time to Measuring Mode, transition time to Lockout Setting Mode, display
refreshing rate, manual sub display reset, P output, latching alarm, alarm power
ON delay, standby sequence, scaling error, round off low-digit reading, display
reading type, high-pass filter, backlight brightness, LCD contrast, bank switching,
REQ input logic, DAV output logic, DATA output logic, status output logic, firmware
version indication
Alarm setting lockout, scaling setting lockout, advanced setting lockout, Modbus
setting lockout, MAX/MIN display control lockout, forced zero control (Up button)
lockout, loop test output lockout, IR communication lockout, Modbus communica-
tion lockout, initialization
Device address, baud rate, parity bit, stop bit, T1.5 timer, T3.5 timer, long register
----
20 times/sec. (50 msec.)
Simple average, moving average or no averaging
Prohibiting certain operations; protecting settings
47DAC OPERATING MANUAL EM-9518-B Rev.4
, stripped length 7 to 8 mm
