36.4.7 LOCKOUT SETTING MODE

* Selectable only with the I/O option code '4' , '7' or '8' (network interface).

36.4.8 LOOP TEST OUTPUT MODE

Measuring Mode
NOTE
Transition to Loop Test Output Mode is available only with the DC output code '1' .
Measurement
stopped
Measuring Mode
Measurement
started
Forced zero control (Up button)
lockout
LV0 (unlock Forced Zero and Tare
Adj. control)
LV1 (unlock Forced Zero control /
lock Tare Adj. control)
LV2 (lock Forced Zero and Tare
Adj. control)
Loop test output lockout
OFF (unlock)
ON (lock)
IR communication lockout
OFF (enable)
ON (disable)
Modbus communication
lockout
OFF (enable)
ON (disable)
Initialization
OFF, RESET
Measurement
+
stopped
for ≥ 5 sec.
or
Measurement
started
for ≥ 1 sec.
+ for a preset time duration
or
for ≥ 1 sec.
Lockout Setting Mode
Loop Test Output Mode
+
Loop test output
-20000 to 100000
47DAC OPERATING MANUAL EM-9518-B Rev.4
Alarm setting lockout
LV1 (partially unlock)
LV2 (lock)
LV0 (completely unlock)
Scaling setting lockout
OFF (unlock)
ON (lock)
Advanced setting lockout
LV1 (partially unlock)
LV2 (lock)
LV0 (completely unlock)
Modbus setting lockout
OFF (unlock)
ON (lock)
MAX/MIN display control
lockout
LV0 (unlock MAX/MIN display
control)
LV1 (lock MAX/MIN display reset)
LV2 (lock MAX/MIN display control)
