M-system 47DAC Operating Manual page 100

4
Press Alarm/↓ or Scale/↑ button to apply the new setting.
• And the next parameter setting is indicated.
NOTE
• Press Alarm/↓ button, and the L (H or HH) alarm setpoint (' A LARM L' , ' A LARM H' or ' A LARMHH' on the SD), or the
display blinking at alarm (' A LMBLNK' on the SD) will be indicated. Or the LL (L, H or HH) trip action will be indicated
('LIMT LL' , 'LIMT L' , 'LIMT H' or 'LIMT HH' on the SD) with the alarm setting lockout set to "completely unlock Alarm Set-
ting Mode" .
• Press Scale/↑ button, and the alarm output pattern (' A LM PTN' on the SD), or the LL (L or H) setpoint (' A LARMLL' ,
' A LARM L' or ' A LARM H' on the SD) will be indicated. Or the alarm output pattern (' A LM PTN' on the SD) or the LL (L
or H) coil at alarm ('RELAYLL' , 'RELAY L' or 'RELAY H' on the SD) will be indicated with the alarm setting lockout set to
"completely unlock Alarm Setting Mode" .
5
■ TO GO ON TO SET ANOTHER ALARM SETPOINTS,
Repeat operation from Step 2.
■ TO SET THE NEXT PARAMETER,
Skip to Step 2 in "9.3 TRIP ACTION (LO/HI)" .
■ TO QUIT,
Hold down Alarm/↓ or Scale/↑ button for 1 second or more to return to Measuring Mode.
47DAC OPERATING MANUAL EM-9518-B Rev.4 100
