NOTE
■ INPUT SCALING SETTING
• Do not set 'input scaling value Zero ≥ input scaling value Span' .
■ IF THE FRONT BUTTONS ARE LEFT UNTOUCHED...
• The indication turns on with applying the last changes after the specified time period (default: 15 sec.) while it is in the
setting standby mode (indication blinking in Step 4 and 5).
• The display goes back automatically to Measuring Mode after the specified time period (default: 15 sec.) in one of the
other modes.
• This time period (automatic return time) is configurable. (Refer to 15. GOING BACK AUTOMATICALLY TO MEASUR-
ING MODE.)
■ TO ABORT A SETTING...
• Hold down Max/Min button for 1 second or more in the setting standby mode (indication blinking in Step 4 and 5) to
return to Measuring Mode without applying the last changes.
• If you get lost in a setting mode, you can execute initialization. (Refer to 35.2 INITIALIZING SETTING VALUES.)
■ SHIFTING DIGITS
• Each time pressing Shift button, the blinking digit moves to the right.
■ SETTING A NUMERICAL VALUE
• Each time pressing Up button, the numeral is incremented by 1.
・・・・・
47DAC OPERATING MANUAL EM-9518-B Rev.4
* 6th digit
61
