31. CONFIGURING PARAMETERS VIA INFRARED COMMUNICATION

The 47DAC is equipped with the infrared communication function in order to read and write parameters with a PC. The
software 47DCFG is downloadable freely at M-System's web site. Prepare the COP-IRU separately.
The infrared communication is convenient in the following cases:
• To configure the same settings to several units.
• To confirm the current settings with a PC.
• To make a backup file for failure.
■ PROCEDURE TO MOVE ON TO INFRARED COMMUNICATION MODE
(1) Hold down Alarm/↓ and Up buttons at once for 3 seconds or more to move on to Infrared Communication Mode.
(2) Hold down Alarm/↓ or Scale/↑ button for 1 second or more to return to Measuring Mode.
Present value
Hold down Alarm/↓ or Scale/↑ for ≥ 1 sec.
*1 Display depends on the settings and input.
Hold down
Infrared Communication Mode
Alarm/↓ + Up
for ≥ 3 sec.
47DAC OPERATING MANUAL EM-9518-B Rev.4
Blinking
