4.1 STEP 1. INPUT SCALING VALUE ZERO

4.1.1 INPUT SCALING LIST

Input scaling default values and setting ranges per input code are as shown in the following tables. The input scaling val-
ues are reset to the default or the previously set values per input type when the input type has been changed.
■ INPUT CODE: 1 [MODEL: 47DAC-1XX-XX]
INPUT TYPE
(MAIN DISPLAY)
0 – 0.2 V
(0.2V)
0 – 2 V
(2V)
0 – 20 V
(20V)
0 – 200 V
(200V)
■ INPUT CODE: 2 [MODEL: 47DAC-2XX-XX]
INPUT TYPE
(MAIN DISPLAY)
0 – 0.2 mA
(0.2MA)
0 – 2 mA
(2MA)
0 – 20 mA
(20MA)
0 – 200 mA
(200MA)
DEFAULT VALUE
Input scaling value Zero:
Input scaling value Span:
Input scaling value Zero:
Input scaling value Span:
Input scaling value Zero:
Input scaling value Span:
Input scaling value Zero:
Input scaling value Span:
DEFAULT VALUE
Input scaling value Zero:
Input scaling value Span:
Input scaling value Zero:
Input scaling value Span:
Input scaling value Zero:
Input scaling value Span:
Input scaling value Zero:
Input scaling value Span:
SETTING RANGE
0.0000 – 0.2000 V
0.000 – 2.000 V
0.000 – 20.000 V
0.00 – 200.00 V
SETTING RANGE
0.0000 – 0.2000 mA
0.000 – 2.000 mA
0.000 – 20.000 mA
0.00 – 200.00 mA
47DAC OPERATING MANUAL EM-9518-B Rev.4 51
