■ REAR VIEW
• With Terminal Cover
Connection diagram
NOTE
• The connection diagram depends on the specifications.
• The MODEL shows the same as that in the specification label on the top of the unit.
• Without Terminal Cover
No Options
Terminal block (separable)
BCD Output, Event Trigger Input, Alarm Output (Photo MOSFET Relay)
Terminal block (separable)
50-pin connector
Euro type connector terminal
Model No.
Alarm Output, RS-485 / Modbus
Strap
Strap
47DAC OPERATING MANUAL EM-9518-B Rev.4
Terminal cover
Strap
Terminal block (separable)
Terminal block (separable)
Strap
