1.6.2 PANEL CUTOUT DIMENSIONS

1.6.3 VIEWING ANGLE

The display is designed to provide the optimal legibility when viewed from the angles as shown below.
+ 0.8
92
– 0
min. 120
Panel thickness: 1.6 to 8.0 mm
47DAC OPERATING MANUAL EM-9518-B Rev.4
unit: mm
19
