11. ADVANCED ALARM SETTING

Advanced alarm operation can be set. You can configure parameters as shown in Tables 1 and 2. Figures 1 to 4 show
alarm examples.
■ TABLE 1: ADVANCED ALARM OUTPUT PARAMETERS
PARAMETER
P output
Latching alarm
Alarm power ON delay
Standby sequence
Scaling error
■ TABLE 2: SETTING VALUES
PARAMETER
P output
Latching alarm
Alarm power ON delay
Standby sequence
Scaling error
FUNCTION
Alarm outputs are normally assigned to the LL, L, H and HH alarms and there is not an output
for the P status. However the P output can be assigned to an output instead of one of the
alarm points (Figure 1).
The alarm output ON except for the P output can be held (Figure 2). Whether the output is
held with the display reading continued to accept measured values, or both output and read-
ing are held, can be selected.
In order to reset the latching, set the latching alarm to "no latching" , turn off the power and
restart, or provide the RESET signal.
The measuring can begin after waiting for the delay time from power on (Figure 3).
The outputs can stand by until the input enters P zone from power on (Figure 4).
An alarm trip when 'S.ERR' is indicated can be set.
MAIN DISPLAY FUNCTION
No P output
Alarm setpoint LL
Alarm setpoint L
Alarm setpoint H
Alarm setpoint HH
No latching
Output latched / measuring continued
Output latched / measuring stopped
0.0 – 999.9 seconds
to
Output immediately at the startup
Output standing by until the input enters P zone
Alarm trip action valid at over-range
No alarm trip action at over-range
47DAC OPERATING MANUAL EM-9518-B Rev.4
DEFAULT VALUE
