Chapter 2: Specifications
C0-01DR-D – 8 DC Input/6 Relay Output Micro PLC (continued)
Built-in I/O Specifications - Outputs
Outputs per Module
Operating Voltage Range
Output Voltage Range
Output Type
Maximum Current
Minimum Load Current
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
6-27 VDC
6-240 VAC
L
6-27 VDC
6-240 VAC
L
2–48
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
6
6–240 VAC (47–63 Hz), 6–27 VDC
5–264 VAC (47–63 Hz), 5–30 VDC
Relay, form A (SPST)
1A/point; C3: 4A/common,
C4: 2A/common
5mA @ 5VDC
3A for 10ms
< 15ms
< 15ms
Logic Side (6 points, red LED)
2 (4 points/com &
2 points/com) Isolated
Equivalent Output Circuit
Internal Module Circuitry
OUTPUT
Y1-Y4
Typical
*
C3 COM
To Y2-Y4
commons
OUTPUT
Y5-Y6
Typical
*
C4 COM
To Y6
common
* Varistor Joule Rating: 20 J
C0-01DR-D Temperature Derating Chart
8
6
Outputs
4
2
0
0 10 20 30
32 50 68 85
Surrounding Air Temperature (°C/°F)
* Use every other output.
Typical Relay Life (Operations)
at Room Temperature
Voltage & Load Type
30VDC, 1A Resistive
30VDC, 1A Solenoid
250VAC, 1A Resistive
250VAC, 1A Solenoid
ON to OFF = 1 cycle
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
20-pin connector cable
ZL-C0-CBL20 (0.5 m length)
ZL-C0-CBL20-1 (1.0 m length)
ZL-C0-CBL20-2 (2.0 m length)
ZL-RTB20
20-pin feed-through
connector module
*
40 50 55 °C
104 122 131 °F
Relay Life
300,000 cycles
50,000 cycles
500,000 cycles
200,000 cycles
