Chapter 6: Troubleshooting
Error Codes (continued)
Error Status Error
Code Flag* Name
IO2 CH3
323 X209
Burnout
IO2 CH4
324 X212
Burnout
IO3 Missing
330 X302
24V
IO3 CH1
331 X303
Burnout
IO3 CH2
332 X306
Burnout
IO3 CH3
333 X309
Burnout
IO3 CH4
334 X312
Burnout
IO4 Missing
340 X402
24V
IO4 CH1
341 X403
Burnout
IO4 CH2
342 X406
Burnout
IO4 CH3
343 X409
Burnout
IO4 CH4
344 X412
Burnout
IO5 Missing
350 X502
24V
IO5 CH1
351 X503
Burnout
IO5 CH2
352 X506
Burnout
IO5 CH3
353 X509
Burnout
* The Status Flags are turned ON when the related errors occur.
Error code table continued on next page.
6–14 CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
PLC Error Codes
Category Causes
CH3 on the analog I/O module in
Warning I/O2 position senses burnout or
open circuit.
CH4 on the analog I/O module in
Warning I/O2 position senses burnout or
open circuit.
The analog I/O module in I/
Warning O3 position is missing external
24VDC input.
CH1 on the analog I/O module in
Warning I/O3 position senses burnout or
open circuit.
CH2 on the analog I/O module in
Warning I/O3 position senses burnout or
open circuit.
CH3 on the analog I/O module in
Warning I/O3 position senses burnout or
open circuit.
CH4 on the analog I/O module in
Warning I/O3 position senses burnout or
open circuit.
The analog I/O module in I/
Warning O4 position is missing external
24VDC input.
CH1 on the analog I/O module in
Warning I/O4 position senses burnout or
open circuit.
CH2 on the analog I/O module in
Warning I/O4 position senses burnout or
open circuit.
CH3 on the analog I/O module in
Warning I/O4 position senses burnout or
open circuit.
CH4 on the analog I/O module in
Warning I/O4 position senses burnout or
open circuit.
The analog I/O module in I/
Warning O5 position is missing external
24VDC input.
CH1 on the analog I/O module in
Warning I/O5 position senses burnout or
open circuit.
CH2 on the analog I/O module in
Warning I/O5 position senses burnout or
open circuit.
CH3 on the analog I/O module in
Warning I/O5 position senses burnout or
open circuit.
Solutions
Check the wiring for CH3.
Replace the sensor if it is broken.
Check the wiring for CH4.
Replace the sensor if it is broken.
Apply 24VDC to the analog I/O module.
Check the wiring for CH1.
Replace the sensor if it is broken.
Check the wiring for CH2.
Replace the sensor if it is broken.
Check the wiring for CH3.
Replace the sensor if it is broken.
Check the wiring for CH4.
Replace the sensor if it is broken.
Apply 24VDC to the analog I/O module.
Check the wiring for CH1.
Replace the sensor if it is broken.
Check the wiring for CH2.
Replace the sensor if it is broken.
Check the wiring for CH3.
Replace the sensor if it is broken.
Check the wiring for CH4.
Replace the sensor if it is broken.
Apply 24VDC to the analog I/O module.
Check the wiring for CH1.
Replace the sensor if it is broken.
Check the wiring for CH2.
Replace the sensor if it is broken.
Check the wiring for CH3.
Replace the sensor if it is broken.
