AutomationDirect C0-USER-M Manual page 114

C0-11DD2E-D – 8 DC Input/6 Sourcing DC Output Micro PLC (continued)
Built-in I/O Specifications - Outputs
Outputs per Module
Operating Voltage Range
Output Voltage Range
Maximum Output Current
Minimum Output Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
Equivalent Output Circuit
24 VDC
+ V1
*
Y1
L
OUTPUT Y1
*
L
OUTPUT Y2-Y4
24 VDC
+ V2
*
L
OUTPUT Y5-Y6
CO COM
*Zener Diode Power Dissipation: 200 mW
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
6 (Source)
24VDC
19.2–30 VDC
0.1 A/point, 0.6 A/common
0.2 mA
0.1 mA @ 30VDC
0.5 VDC @ 0.1 A
150mA for 10ms
Max. 0.5 ms
Max. 0.5 ms
Logic Side (6 points, red LED)
1 (6 points/common)
Internal Module Circuitry
Optical Isolator
High response
circuit
Optical Isolator
High response
circuit
Optical Isolator
High response
circuit
Chapter 2: Specifications
C0-11DD2E-D Temperature Derating Chart
8
6
Outputs
4
2
0
0 10 20 30
32 50 68 85
Surrounding Air Temperature (°C/°F)
* Use every other output.
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
20-pin connector cable
ZL-C0-CBL20 (0.5 m length)
ZL-C0-CBL20-1 (1.0 m length)
ZL-C0-CBL20-2 (2.0 m length)
ZL-RTB20
20-pin feed-through
connector module
*
40 45 50 55 °C
104 113 122 131 °F
2–71
