PLC Unit System
2.6
34.9
[0.102]
[1.37]
85 85 5
[3.35] .35] 5
4
[0.16]
9.2
[0.36]
Maximum system: Power Supply + PLC + eight I/O modules.
Follow the installation guidelines to allow for proper spacing from other components within
an enclosure.
C0-01AC
CLICK PLC Hardware User Manual, 5th Edition, Rev. F – C0-USER-M
53.5 27
[2.11] [1.06]
"
304.4
[11.98]
Chapter 3: Installation and Wiring
13.5
[0.46]
75
[2.95]
9.4
[0.37]
Unit Dimensions
mm [inches]
