AutomationDirect C0-USER-M Manual page 15

C
C
C
hapter
hapter
hapter
1
1
1
G S
ettinG tarted
In This Chapter...
Introduction .............................................................................................................. 1-2
Conventions Used ..................................................................................................... 1-3
Before you begin... ................................................................................................... 1-4
Step 1: Install Programming Software..................................................................... 1-5
Step 2: Launch Programming Software ................................................................... 1-6
Step 3: Create a Project ............................................................................................ 1-8
Step 4: Compile and Save Project .......................................................................... 1-14
Step 5: Apply Power ............................................................................................... 1-15
Step 6: Establish PC to PLC Communications........................................................ 1-16
Step 7: Write Project into PLC ............................................................................... 1-24
Step 8: Place PLC in RUN Mode ............................................................................. 1-25
Step 9: Test Project using Data View Monitor ...................................................... 1-26
Step 10: Y001 Output On? ..................................................................................... 1-27
Additional Training Resources ................................................................................ 1-28
