C0-08TD1 – 8-Point Sinking DC Output Module
8-pt 3.3–27 VDC current sinking output module, 2 commons, 0.3 A/pt, removable terminal
block included.
PWR PWR
Wiring Diagram
L
L
3.3 - 27VDC
L
L
L
L
24VDC
L
3.3 - 27VDC
L
Equivalent Output Circuit
Internal Module Circuitry
24 VDC
+
+V
+ OUTPUT
L
3.3 - 27 VDC
*
COM
* Zener Diode Power Dissipation: 200 mW
Output Module Temperature Derating Chart
8
6
4
2
0
0 10
32 50
Surrounding Temperature (°C/°F)
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
C0 08TD1 C0-08TD1
Outputs per Module
3.3-27V 0.3A 3.3-27V 0.3A
Operating Voltage Range
Output Voltage Range
Maximum Output Current
Minimum Output Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
C1
OFF to ON Response
1
2
ON to OFF Response
3
Status Indicators
4
C2
Commons
5
6
External DC Power Required
7
8
Bus Power Required (24VDC)
+V
Terminal Block Replacement
Weight
Optical Isolator
20 30 40 50
68 85 104 122
Output Specifications
8 (Sink)
3.3–27 VDC
2.8–30 VDC
0.3 A/point , 1.2 A/common
0.5 mA
0.1 mA @ 30.0 VDC
1.5 VDC @ 0.3 A
1A for 10ms
< 0.5 ms
< 0.5 ms
Logic Side (8 points, red LED)
Power Indicator (green LED)
2 (4 points/common)
21.6–26.4 VDC Max 15mA
(All Outputs On)
Max. 50mA (All Outputs On)
ADC p/n C0-8TB
2.8 oz (80g)
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
11-pin connector cable
ZL-C0-CBL11 (0.5 m length)
ZL-C0-CBL11-1 (1.0 m length)
ZL-C0-CBL11-2 (2.0 m length)
ZL-RTB20
20-pin feed-through
connector module
55 °C
131 °F
