C0-08CDR (continued)
Output Specifications
Outputs per Module
Operating Voltage Range
Peak Voltage
Output Type
AC Frequency
Maximum Current
Minimum Load Current
Maximum Leakage Current
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
Equivalent Output Circuit
24 VDC
240 VAC
OUTPUT
L
COM
Output Temperature Derating Chart
4
3
2
1
0
0 10 20
32 50 68
Surrounding Air Temperature (°C/°F)
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
4 (Relay)
CE: 6.25–24 VDC (-15%/+10%) /
6–240 VAC (-15%/+10%)
UL: 24VDC (-15%/+10%) /
240VAC (-10%/+10%)
30VDC / 264VAC
Relay, Form A (SPST)
47–63 Hz
1A /point, 4 A/common
5mA @ 5VDC
0.1 mA @ 264VAC
3A for 10ms
<15ms
<15ms
Logic Side (4 points, red LED)
1 (4 points/common)
Internal Module Circuitry
30 40 50 55 °C
85 104 122 131 °F
Chapter 2: Specifications
Typical Relay Life
(Operations) at Room Temperature
Voltage & Load Type*
30VDC, 1A, Resistive
30VDC, 1A, Solenoid
250VAC, 1A, Resistive
250VAC, 1A, Solenoid
* These relay outputs support both inductive (solenoid)
and resistive loads.
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
ZL-RTB20
20-pin feed-through
connector module
11-pin connector cable
ZL-C0-CBL11 (0.5 m length)
ZL-C0-CBL11-1 (1.0 m length)
ZL-C0-CBL11-2 (2.0 m length)
Relay Life
(ON to OFF = 1 cycle)
80,000 cycles
80,000 cycles
80,000 cycles
80,000 cycles
