Chapter 2: Specifications
C0-12DRE-D – 4 DC Input (Sink/Source)/4 Relay Output;

2 Analog Voltage/Current Input

2 Analog Voltage/Current Output Micro PLC

PWR PWR PWR
RUN RUN
ERR ERR
PORT1 PORT1
LNK/ACT LNK/ACT
ETHER ETHER ETHER
NET NET NET NET
100MBIT 100MBIT 100MBIT 100MBIT
PORT2 PORT2
TX2 TX2
RX2 RX2
RS-232 RS 232 RS-232
RS- RS-485 -485 5
PO O RT3 PO O RT3 PORT3
TX3 TX X 3
RX3 RX X 3
General Specifications
Current Consumption at 24VDC
Terminal Block Replacement Part No.
Weight
WARNING: When using an Ethernet Analog PLC unit, you must use CLICK programming software
version V2.20 or later.
NOTE: Please refer to the Analog I/O Configuration section in Chapter 3 for information on using the
analog I/O.
NOTE: There are no ZIPLink pre-wired PLC connection cables and modules for the Ethernet Analog PLCs
(cannot mix discrete I/O and analog I/O signals in a ZIPLink cable).
2–82
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
C0-12DRE-D
C1
X1
X2
R R RUN R R R UN RUN
X3
X4
S S S S STOP S S TOP STOP S S TOP
C2
Y1
Y2
Y3
Y4
AD1V
AD1 I
AD2V
AD2 I
ACOM
485 5
DA1V
+ + +
DA1 I
_ _ _
DA2V
DA2 I
LG LG G
160mA
C0-16TB
5.4 oz (155g)
Wiring Diagram
24VDC
6–27 VDC
L
6–240 VAC
L
L
L
Transmitter 0-5V
Transmitter 4-20mA
Transmitter 0-5V
Transmitter 4-20mA
Transmitter
P/S
See Discrete I/O Specifications
Inputs (X1 – X4) High-Speed
See Discrete I/O Specifications
Outputs (Y1 – Y4)
See Analog I/O Specifications
Voltage & Current
Inputs (AD1V – AD2I)
See Analog I/O Specifications
Voltage & Current
Outputs (DA1V – DA2I)
