Chapter 2: Specifications
C0-00DD1-D – 8 DC Input/6 Sinking DC Output Micro PLC (continued)
Built-in I/O Specifications - Outputs
Outputs per Module
Operating Voltage Range
Output Voltage Range
Maximum Output Current
Minimum Output Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
External DC Power
Required
24 VDC
+V
+
OUTPUT
Y1
+
L
5 - 27 VDC
OUTPUT
Y2-Y4
+
L
5 - 27 VDC
C3 COM
OUTPUT
Y5-Y6
+
L
5 - 27 VDC
C4 COM
* Zener Diode Power Dissipation: 200 mW
2–36
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
6 (Sink)
5–27 VDC
4–30 VDC
0.1 A/point; C3: 0.4 A/common,
C4: 0.2 A/common
0.2 mA
0.1 mA @ 30.0 VDC
0.5 VDC @ 0.1 A
150mA for 10ms
Y1: typ 5μs; Max 20μs
Y2-6: < 0.5 ms
Y1: typ 5μs; Max 20μs
Y2-6: < 0.5 ms
Logic Side (6 points, red LED)
2 (4 points/com & 2 points/com)
20–28 VDC Maximum @ 60mA
(All Points On)
C0-00DD1-D
Equivalent Output Circuit
Internal Module Circuitry
Optical Isolator
High response
*
circuit
Optical Isolator
*
Optical Isolator
*
Note: C3 & C4 are not internally connected.
C0-00DD1-D Temperature Derating Chart
8
6
Outputs
4
2
0
0 10 20 30
32 50 68 85
Surrounding Air Temperature (°C/°F)
* Use every other output.
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
20-pin connector cable
ZL-C0-CBL20 (0.5 m length)
ZL-C0-CBL20-1 (1.0 m length)
ZL-C0-CBL20-2 (2.0 m length)
ZL-RTB20
20-pin feed-through
connector module
*
40 50 55 °C
104 122 131 °F
