C0-12DD1E-2-D (continued)
X1 - X4 (High-Speed)
Discrete I/O Specifications - Inputs
Inputs per Module
Operating Voltage Range
Input Voltage Range
Input Current
Max. Input Current
Input Impedance
ON Voltage Level
OFF Voltage Level
Minimum ON Current
Maximum OFF Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
Y1 - Y4
Discrete I/O Specifications - Outputs
Outputs per Module
Operating Voltage Range
Maximum Output Current
Minimum Output Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
External DC Power
Required
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
4 (Source/Sink)
24VDC
21.6–26.4 VDC
Typ 6.5 mA @ 24VDC
7mA @ 26.4 VDC
3.9 kq @ 24VDC
>19VDC
< 2VDC
4.5 mA
0.5 mA
Typ 3μs Max 5μs
Typ 1μs Max 3μs
Logic Side (4 points, green LED)
1 (4 points/common)
4 (Sink)
5–27 VDC
0.1 A/point; 0.4 A/common
0.2 mA
0.1 mA @ 30.0 VDC
0.5 VDC @ 0.1 A
150 mA for 10ms
5μs
5μs
Logic Side (4 points, red LED)
1 (4 points/common)
20–28 VDC Maximum @ 60mA
(All points on)
Chapter 2: Specifications
Equivalent Discrete Input Circuit
24 VDC
INPUT
X1-X4
+
+
COM
C1
C0-12DD1E-2-D Temperature Derating Chart
4
3
2
1
0
0
10
20
32
50
68
Surrounding Air Temperature (°C/°F)
Equivalent Discrete Output Circuit
Internal Module Circuitry
24VDC
+
+V
+
Y1–Y4
L
5–27
VDC
C2
C0-12DD1E-2-D Temperature Derating Chart
4
Outputs
3
2
1
0
0
10
20
32
50
68
Surrounding Air Temperature (°C/°F)
Internal Module Circuitry
Optical Isolator
VCC
GND
Inputs
30
40
50
55 °C
85
104
122
131 °F
3.3 V
Optical Isolator
VCC
GND
30
40
50
55 °C
85
104
122
131 °F
2–101
3.3 V
