Chapter 2: Specifications
C0-08TD2 – 8-Point Sourcing DC Output Module
8-pt 12–24VDC current sourcing output module, 1 common, 0.3 A/pt, removable terminal
block included.
Wiring Diagram
12 - 24VDC
12 - 24VDC
12-24 VDC
+ +V
OUTPUT
L
COM
* Zener Diode Power Dissipation: 200 mW
Output Module Temperature Derating Chart
8
6
4
2
0
0
32
2–120
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
C0-08TD2 C0-08TD2
PWR PWR
12-24V 0.3A 12-24V 0.3A
V1
1
L
2
L
3
L
4
L
V2
5
L
6
L
7
L
8
L
C
Equivalent Output Circuit
Internal Module Circuitry
*
10 20 30 40
50 68 85 104
Surrounding Temperature (°C/°F)
Output Specifications
Outputs per Module
Operating Voltage Range
Output Voltage Range
Maximum Output Current
Minimum Output Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
Bus Power Required (24VDC)
Terminal Block Replacement
Weight
Optical Isolator
50 55 °C
122 131 °F
8 (Source)
12–24VDC
9.6–30 VDC
0.3 A/point , 1.2 A/common
0.5 mA
0.1 mA @ 30.0 VDC
1.5 VDC @ 0.3 A
1A for 10ms
< 1ms
< 1ms
Logic Side (8 points, red LED)
Power Indicator (green LED)
1 (8 points/common)
Max. 50mA (All Outputs On)
ADC p/n C0-8TB
2.8 oz (80g)
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
11-pin connector cable
ZL-C0-CBL11 (0.5 m length)
ZL-C0-CBL11-1 (1.0 m length)
ZL-C0-CBL11-2 (2.0 m length)
ZL-RTB20
20-pin feed-through
connector module
