Chapter 2: Specifications
C0-01DD2-D – 8 DC Input/6 Sourcing DC Output Micro PLC (continued)
Built-in I/O Specifications - Outputs
Outputs per Module
Operating Voltage Range
Output Voltage Range
Maximum Output Current
Minimum Output Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
24 VDC
V1
+
*
Y1
L
OUTPUT Y1
*
L
OUTPUT Y2-Y4
24 VDC
V2
+
*
L
OUTPUT Y5-Y6
CO COM
*Zener Diode Power Dissipation: 200 mW
2–46
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
6 (Source)
24VDC
19.2–30 VDC
0.1 A/point , 0.6 A/common
0.2 mA
0.1 mA @ 30VDC
Y1: 1.0 VDC @ 0.1 A
Y2-6: 0.5 VDC @ 0.1 A
150mA for 10ms
Y1: Typ 5μs; Max 20μs
Y2-6: < 0.5 ms
Y1: Typ 5μs; Max 20μs
Y2-6: < 0.5 ms
Logic Side (6 points, red LED)
1 (6 points/common)
Equivalent Output Circuit
Internal Module Circuitry
Optical Isolator
High response
circuit
Optical Isolator
Optical Isolator
C0-01DD2-D Temperature Derating Chart
8
6
Outputs
4
2
0
0 10 20 30
32 50 68 85
Surrounding Air Temperature (°C/°F)
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
20-pin connector cable
ZL-C0-CBL20 (0.5 m length)
ZL-C0-CBL20-1 (1.0 m length)
ZL-C0-CBL20-2 (2.0 m length)
ZL-RTB20
20-pin feed-through
connector module
40 50 55 °C
104 122 131 °F
