C0-16CDD2 (continued)
Output Specifications
Outputs per Module
Operating Voltage Range
Output Voltage Range
Maximum Output Current
Minimum Output Current
Maximum Leakage Current
On Voltage Drop
Maximum Inrush Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
Equivalent Output Circuit
12-24 VDC
+
+V
*
OUTPUT
L
COM
* Zener Diode Power Dissipation: 200 mW
Output Module Temperature Derating Chart
8
6
4
2
0
0 10
32 50
Surrounding Temperature (°C/°F)
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
8 (Source)
CE: 12–24 VDC (-15%/+20%)
UL: 12–24 VDC (-20%/+25%)
9.6–30 VDC
0.1 A/point , 0.8 A/common
0.2 mA
0.1 mA @ 30VDC
0.6 VDC @ 0.1 A
0.15 A for 10ms
<0.5 ms
<0.5 ms
Logic Side (8 points, red LED)
1 (8 points/common)
Internal Module Circuitry
Optical Isolator
20 30 40 50 55 °C
68 85 104 122 131 °F
Chapter 2: Specifications
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
ZL-RTB20
20-pin feed-through
connector module
20-pin connector cable
ZL-C0-CBL20 (0.5 m length)
ZL-C0-CBL20-1 (1.0 m length)
ZL-C0-CBL20-2 (2.0 m length)
