C0-16TD1 – 16-Point Sinking DC Output Module
16-pt 5–27 VDC current sinking output module, 2 commons, isolated, 0.1 A/pt, removable
terminal block included.
Wiring Diagram
PWR PWR
L
L
24VDC
L
L
L
L
L
5 - 27VDC
L
L
L
24VDC
L
L
L
L
L
5 - 27VDC
L
Equivalent Output Circuit
Internal Module Circuitry
24 VDC
+
+V
+
OUTPUT
L
5 - 27 VDC
*
COM
* Zener Diode Power Dissipation: 200 mW
Output Module Temperature Derating Chart
16
12
8
4
0
0 10 20 30
32 50 68 85
Surrounding Temperature (°C/°F)
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
C0-16TD1 C0-16TD1
5-27V 0.1A 5-27V 0.1A
Outputs per Module
C1
Operating Voltage Range
1
Output Voltage Range
2
Maximum Output Current
3
Minimum Output Current
4
V1
Maximum Leakage Current
5
On Voltage Drop
6
Maximum Inrush Current
7
OFF to ON Response
8
ON to OFF Response
C2
9
Status Indicators
10
Commons
11
12
External DC Power Required
V2
13
Bus Power Required (24VDC)
14
Terminal Block Replacement
15
Weight
16
Optical Isolator
ZL-RTB20 20-pin
feed-through
40 50 55 °C
104 122 131 °F
connector module
Chapter 2: Specifications
Output Specifications
16 (Sink)
5–27 VDC
4–30 VDC
0.1 A/point , 0.8 A/common
0.2 mA
0.1 mA @ 30.0 VDC
0.5 VDC @ 0.1 A
150mA for 10ms
< 0.5 ms
< 0.5 ms
Logic Side (16 points, red LED)
Power Indicator (green LED)
2 (8 Points/common) Isolated
21.6–26.4 VDC Max 100mA
(All Outputs On)
Max. 80mA (All Outputs On)
ADC p/n C0-16TB
3.2 oz (90g)
ZIPLink Pre-Wired PLC Connection
Cables and Modules for CLICK PLC
20-pin connector cable
ZL-C0-CBL20 (0.5 m length)
ZL-C0-CBL20-1 (1.0 m length)
ZL-C0-CBL20-2 (2.0 m length)
ZL-RRL16-24-1 relay module
ZL-RFU20 Note: 10A/Point (DC)
fuse module
(Replaceable relays)
8A/Point (AC)
2–121
