Chapter 2: Specifications
C0-10DD2E-D – 8 DC Input/6 Sourcing DC Output Micro PLC
PWR PWR PWR R R R UN RUN R R R R RUN
RUN RUN
STOP S S S S S S TOP S S TOP STOP
ERR ERR
PORT1 PORT1
LNK/ACT LNK/ACT
ETHER ETHER ETHER
NET NET NET NET
100MBIT 100MBIT 100MBIT 100MBIT
PORT2 PORT2
TX2 TX2
RX2 RX2
RS 232 RS-232 RS-232
NOTE: When using Ethernet Basic PLCs,
you must use CLICK programming
software version V2.00 or later.
Equivalent Input Circuit
INPUT
X1-X4
Typical
+
+
24 VDC
C1 COM
INPUT
X5-X8
Typical
+
+
24 VDC
C2 COM
2–62
CLICK PLC Hardware User Manual, 6th Edition, Rev. F – C0-USER-M
Wiring Diagram
X1-X4 Inputs
High-Speed
C0-10D C0-10DD2E-D D2E- -D D
24VDC
C1 C1
X1 X1
X2 X2 2
X3 X3 3
X4 X4 4 X4 4
C2 C2 C2 2 2
X5 X5 X5 5 5
X6 X6 X6 6 6
X7 X7 X7 7 X7 7 7
X8 X8 8 X8 8
V1 V1 V1
L
Y1 Y1 Y1
L
Y2 Y2 2 Y2 2
Y3 Y3 3 Y3 3 L
Y4 Y4 4 Y4 4 L
V2 V2 2 V2 2
L
Y5 Y5 5
Y6 Y6 6 L
CO CO O
Internal Module Circuitry
Optical Isolator
To X2-X4
commons
Optical Isolator
To X6-X8
commons
Built-in I/O Specifications - Inputs
Inputs per Module
Operating Voltage Range
Input Voltage Range
Input Current
Maximum Input Current
Input Impedance
Input Frequency (Max)
ON Voltage Level
OFF Voltage Level
24VDC
Minimum ON Current
Maximum OFF Current
OFF to ON Response
ON to OFF Response
Status Indicators
Commons
General Specifications
Current Consumption at 24VDC
Terminal Block Replacement Part No.
Weight
C0-10DD2E-D Temperature Derating Chart
8
6
4
2
0
0
32
Surrounding Air Temperature (°C/°F)
* Use every other input.
8 (Sink/Source)
24VDC
21.6–26.4 VDC
X1-4: Typ 6.5 mA @ 24VDC
X5-8: Typ 4mA @ 24VDC
X1-4: 7.0 mA @ 26.4 VDC
X5-8: 5.0 mA @ 26.4 VDC
X1-4: 3.9 kΩ @ 24VDC
X5-8: 6.8 kΩ @ 24VDC
X1-X4: 100kHz
> 19VDC
X1-4: < 2VDC
X5-8: < 7VDC
X1-4: 4.5 mA
X5-8: 3.5 mA
X1-4: 0.5 mA
X5-8: 1.5 mA
X1-4: Typ 3μs Max 5μs
X5-8: Typ 2ms Max 10ms
X1-4: Typ 1μs Max 3μs
X5-8: Typ 3ms Max 10ms
Logic Side (8 points, green LED)
2 (4 points/common) Isolated
120mA
C0-16TB
5.0 oz (140g)
Inputs
10 20 30 40 45
50 68 85 104 113
*
50 55 °C
122 131 °F
