Chapter 3: Installation and Wiring

CLICK I/O Modules

Several different types of input and output modules are available for the CLICK PLC system.
Please see the diagrams below to familiarize yourself with the I/O module features.
Each I/O module is identified as an Input or Output module on its front panel using the color
coding scheme listed below. Up to eight I/O option modules can be connected to a CLICK
PLC. See Mounting Guidelines in this chapter for module dimensions and Chapter 2 for
CLICK I/O module specifications.
Input Modules
Mounting Tab
Power Indicator
(Green: Module Power Good)
Input Point
Status Indicators
(Green: ON)
Mounting Tab
3–8
CLICK PLC Hardware User Manual, 5th Edition, Rev. F – C0-USER-M
Sliding Latch
Module
Part Number
Module Type
(Green: Module Power Good)
(Blue: Input)
DIN Rail Slot and
I/O Module Port
Extension
Module Input
Point Identifier
Removable
Terminal Block
Sliding Latch
Output Modules
Mounting Tab
Power Indicator
Output Point
Status Indicators
(Red: ON)
Mounting Tab
Sliding Latch
Module
Part Number
Module Type
(Red: Output)
DIN Rail Slot and
I/O Module Port
Extension
Module Output
Point Identifier
Removable
Terminal Block
Sliding Latch
