Appendix B. MachXO5T-NX Development Board Bill of Materials

Item Reference
1 CN1
2 CN2,CN3
3 C1,C3,C129,C130
C2,C4,C6,C7,C10,C11,C12,
C13,C14,C17,C29,C30,C34,
C81,C85,C86,C90,C92,C94,
C96,C98,C99,C100,C101,
C113,C114,C122,C123,C124,
C125,C127,C128,C131,C132,
C133,C134,C135,C136,C140,
C141,C142,C144,C145,C146,
C147,C148,C149,C150,C151,
C153,C155,C178,C179,C180,
4 C181,C182,C183,C184,C185,
C214,C215,C225,C226,C227,
C228,C229,C230,C231,C233,
C236,C239,C241,C245,C247,
C250,C254,C257,C258,C260,
C267,C269,C270,C271,C272,
C274,C279,C281,C282,C283,
C284,C285,C286,C287,C288,
C289,C290,C291,C292,C293,
C294,C295,C296,C297,C298,
C302,C304
C5,C31,C32,C33,C35,C37,
C39,C42,C45,C49,C52,C55,
C61,C65,C66,C80,C95,C97,
5
C103,C121,C137,C154,C217,
C242,C243,C244,C246,C255,
C263,C268,C278,C280
C8,C9,C18,C19,C138,C139,
6
C276,C277
7 C15,C16
8 C20,C22,C24,C26
9 C21,C23,C25,C27
C28,C87,C224,C232,C237,
10 C238,C240,C252,C253,C256,
C259,C275,C299,C303,C305
