Lattice Semiconductor MachXO3D Quick Start

QuickSTART
This document provides a brief introduction to the Lattice Sentry Demo Board for
MachXO3D.
Power Jack (J11)
MachXO3D-9400C (U4)
ECP5 (U21) status LEDs
ECP5-85F
(U21)
External SPI Flash
for U21, primary and
backup
1

Check Kit Contents

The Lattice Sentry Demo Board for MachXO3D includes the following items:
Lattice Sentry Demo Board for MachXO3D
„
12 V AC/DC Adapter
„
USB Cable for Programming via PC (USB-A to Mini-B)
„
Quick Start Guide
„
2

Using the Board

The Board contains one MachXO3D-9400C (U4) and two ECP5-85F (U11, U21) FGPA
devices.
The board comes pre-loaded with the demonstration program described below. The
MachXO3D program image is contained in its on-board flash. The ECP5 images are
contained in their respective external SPI Flash devices (U17, U18, U27, U28).
12 V DC
Power status LEDs
Lattice Sentry Demo Board
for MachXO3D
MachXO3D status LEDs
ECP5 (U11) status LEDs
ECP5-85F (U11)
External SPI Flash for U11,
primary and backup
