Table 12.6. Arduino J5 Pin Connections

J5 Pin Number Net Name
1 AR_AD0
2 AR_AD1
3 AR_AD2
4 AR_AD3
5 AR_AD4
6 AR_AD5

12.3. FPC Headers

The board provides two 50-Pin FPC headers, CN2 and CN3, for board signal extension. Each header got 14 pairs of LVDS
or SLVS signals for high-speed data transmitter or receiver. CN2 and CN3 are designed to support loopback test with a
standard 50-pin FPC cable.

Table 12.7. FPC Header Pin Connections

CN2 at the Top Side
Pin Number Net Name
1 NC
2 TP3
3 TP3
4 TP3
5 TP3
6 NC
7 SLVS_TP1
8 GND
9 SLVS_DP26
10 SLVS_DN26
11 GND
12 SLVS_DP27
13 SLVS_DN27
14 GND
15 SLVS_DP0
16 SLVS_DN0
17 GND
18 SLVS_DP1
19 SLVS_DN1
20 GND
21 SLVS_DP2
22 SLVS_DN2
23 GND
24 SLVS_DP3
25 SLVS_DN3
26 GND
27 SLVS_DP4
28 SLVS_DN4
29 GND
© 2023 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02058-1.0
Arduino ZERO Board Signal
D14/ADC0/PA02
D15/ADC1/PB08
D16/ADC2/PB09
D17/ADC3/PA04
D18/ADC4/PA05
D19/ADC5/PB02
CertusPro-NX
Ball Location
—
—
—
—
—
—
V6
—
W4
Y4
—
W5
Y5
—
W13
W12
—
V11
U12
—
Y12
Y13
—
W9
W10
—
V12
W11
—
LFMXO5-100T Ball
Comments
Location
M1 Defaults to ADC0 on Arduino ZERO Board.
M2 Defaults to ADC1 on Arduino ZERO Board.
M3 Defaults to ADC2 on Arduino ZERO Board.
M4 Defaults to ADC3 on Arduino ZERO Board.
M5 Defaults to ADC4 on Arduino ZERO Board.
M6 Defaults to ADC5 on Arduino ZERO Board.
CN3 at the Bottom Side
Pin Number Net Name
50
49
48
47
46
45
44 SLVS_TP2
43 GND
42 SLVS_DP24
41 SLVS_DN24
40 GND
39 SLVS_DP25
38 SLVS_DN25
37 GND
36 SLVS_DP12
35 SLVS_DN12
34 GND
33 SLVS_DP13
32 SLVS_DN13
31 GND
30 SLVS_DP14
29 SLVS_DN14
28 GND
27 SLVS_DP15
26 SLVS_DN15
25 GND
24 SLVS_DP16
23 SLVS_DN16
22 GND
MachXO5T-NX-Development Board
Evaluation Board User Guide
CertusPro-NX
Ball Location
NC —
TP4 —
TP4 —
TP4 —
TP4 —
NC —
W6
—
Y2
Y3
—
V1
W1
—
U13
V13
—
R13
T13
—
P12
R12
—
U10
V10
—
U9
V9
—
