3. Hard JTAG/I
2
The hardened JTAG/I C programming architecture of the MachXO5T-NX Development Board is shown in
board has a built-in download controller for programming the LFMXO5-100T device. It uses an FT2232H Future
Technology Devices International (FTDI) part U1 to convert USB to JTAG from port A, or convert USB to I
Using Detect Cable function with Radiant programming software installed, you can detect dual ports after power up
the board and connect the mini USB to USB-A cable from J11 to your PC,ensuring FTDI reset control jumper JP9 is not
populated as default. The software select option FTUSB-0 is dedicate for hard JTAG and FTUSB-1 is dedicated for hard
2
I C which is mapping with port A and port B from hardware perspective, as shown in
Mini-USB
USB
(J11)
JP9
GND
© 2023 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
12
2
C Programming
JP27
Port B
FT2232H
(U1)
TMS
TDO
Port A
TDI
rst#
TCK
2
Figure 3.1. JTAG/I C Programming Architecture
