12.5. Raspberry Pi Board GPIO Header

The MachXO5T-NX Development Board provides a 40-pin receptacle that is compatible with the GPIO header of
Raspberry Pi 2/3 serial models.

Table 12.9. Raspberry Pi J6 Header Pin Connections

J6 Pin Number Net Name
1 3.3V_RASP*
3 RASP_IO02
5 RASP_IO03
7 RASP_IO04
9
11 RASP_IO17
13 RASP_IO27
15 RASP_IO22
17 3.3V_RASP*
19 RASP_IO10
21 RASP_IO09
23 RASP_IO11
25
27 RASP_ID_SD
29 RASP_IO05
31 RASP_IO06
33 RASP_IO13
35 RASP_IO19
37 RASP_IO26
39
Notes:
*
3.3 V power is supplied from Raspberry Pi board.
**
5 V power can come from either the Raspberry Pi board or the MachXO5T-NX Development Board when jumper JP7 is installed.
When jumper JP7 is not installed, both boards need their own 5 V power.

12.6. PMOD Headers

The MachXO5T-NX Development Board provides two 12-pin receptacle headers that is compatible with the Digilent
™
PMOD interface spec.

Table 12.10. J15 Header Pin Connections

J15 Pin Number Net Name
1 PMOD0_1
2 PMOD0_2
3 PMOD0_3
4 PMOD0_4
5
6 VCCIO2
