12.2. Arduino Board GPIO Headers

The board provides four headers, J2, J3, J4, and J5, for Arduino Zero board adaption.

Table 12.3. Arduino J2 Pin Connections

J2 Pin
Net Name
Number
1 AR_IO8
2 AR_IO9
3 AR_SS_IO10
4 AR_MOSI_IO11
5 AR_MISO_IO12
6 AR_SCK_IO13
7 GND
8 AR_AREF
9 AR_SDA
10 AR_SCL

Table 12.4. Arduino J3 Pin Connections

J3 Pin Number Net Name
1 AR_IO0
2 AR_IO1
3 AR_IO2
4 AR_IO3
5 AR_IO4
6 AR_IO5
7 AR_IO6
8 AR_IO7

Table 12.5. Arduino J4 Pin Connections

J4 Pin Number Net Name
1 AR_IO14
2 NC
3 AR_RESET
4 +3.3V_AR
5 AR_5V
6 GND
7 GND
8 +12V
Note:
If JP6 is installed, 5 V power can be supplied from either the Arduino board or the MachXO5T-NX Development Board. With JP6
removed, both boards need their own 5 V power.
