Configuring The Processor With Unity Pro - ProSoft Technology ProTalk PTQ-PDPMV1 User Manual

PTQ-PDPMV1 ♦ Quantum Platform
PROFIBUS DP Master Network Interface Module for Quantum
3

Configuring the Processor with Unity Pro

In This Chapter

Importing the Functional Module ........................................................... 60

Function Blocks Operation Overview .................................................... 79

Derived Function Blocks Overview ........................................................ 82

Using Mailbox Function Blocks .............................................................. 85

Mailbox Overview .................................................................................. 91
ProSoft Technology, Inc.
August 12, 2014
Configuring the Processor with Unity Pro
Page 59 of 306
User Manual
